METALOTERM US - For high temperatures in negative pressure operation
The US system is a modular concentric balanced flue system, made of stainless steel which combines air inlet and flue. US is suitable for high temperature, non-condensing applications with flue gasses in negative pressure. It can be applied on all types of balanced flue gas-fired stoves (class C11 and C31).
High temperature, non-condensing applications
Balanced flue gas-fired stoves (class C11 and C31)
This superb animation shows how easy it is to install with an inset stove and a horizonatal terminal.
Helpful sections for chimney installers
| Basic data (dimensions, weight & co.) | |
Wall thickness per diameter (internal) |
0,4 mm |
Wall thickness per diameter (outside) |
0,4 mm |
| Application | |
Flue gas temperature (dry) |
≤ 600 °C |
Short firing temperature under negative pressure |
≤ 600 °C |
Material (Inner liner) |
AISI 304-EN 1.4301 |
Material (Outer case) |
AISI 304-EN 1.4301 |
| General product features | |
Operating |
Negative pressure (N), Dry |
Room sealed |
Yes |
Occupation |
Single |
Suitable for passive house |
No |
Heating technology |
Condensing boiler technology, Low temperature technology |
