XE & XD

Highlights

Quicklinks

Quality flex liner
Fast installation
Shape stability

Quality flex liner

The XD system features a double-layer design with a smooth inner wall for improved durability and ease of maintenance, while the XE system offers a single-layer, flexible solution with high crush resistance and superior leak-proof construction. These properties make XD and XE versatile and dependable choices for chimney relining in diverse renovation scenarios. The XD system is suitable for higher temperature applications up to 600°C, while the XE system is designed for temperatures up to 260°C, providing robust and flexible solutions for a variety of residential heating needs. Our flexible systems feature high corrosion resistance, with the XD model using 316L stainless steel for both inner and outer layers.

Fast installation

Schiedel's XD and XE flue gas systems offer unparalleled ease and speed of installation (Twist & Fix) in existing chimneys without extensive demolition work. Both systems are designed for compatibility with Metaloterm® and Schiedel systems.

Shape stability

The XD also boasts high shape stability even after multiple bends, maintaining a smooth, protective inner layer that reduces soot and condensate buildup and remains easy to clean. Additionally, the XE system features a leak-proof construction with a dovetail folded seam for superior durability, high crush resistance due to deep ribbing, and the ability to withstand twisting during installation.

Details & Services

Find out more about the details and services for the XD & XE flue gas systems, such as the design, detailed technical data or suitable services. You also have the option of downloading flyers or brochures about the product.

Hover to zoom

The structure of the system

The installation starts with the existing chimney structure, which can be a masonry or structural channel that may need renovation or diameter reduction. The flexible liner is inserted into the existing chimney from the top. Its flexibility allows it to navigate bends and offsets in the chimney structure. At the top of the chimney, a top plate is installed to secure the liner in place. A rain cap is then fitted over the top plate to prevent rain and debris from entering the chimney.

Technical data

Basic data (dimensions, weight & co.)
Wall thickness per diameter (internal)	0,1 mm

Application
Operating temperature under negative pressure	600 °C
Operating temperature under positive pressure	200 °C
Short firing temperature under positive pressure	200 °C
Short firing temperature under negative pressure	600 °C
Operating pressure	200 Pa
Material (Outer case)	AISI 316L, EN 1.4404

General product features
Operating	Humid, Negative pressure (N), Positive pressure (P-H)
