MULTI - The air flue system for decentralized fireplaces
The MULTI is an air/flue gas system for multiple occupancy of gas-fired floor heating systems such as condensing boilers and low-temperature fireplaces in ambient air-independent and ambient air-independent operation. The system consists of lightweight concrete casing bricks and ceramic pipes. We have summarized all the advantages of the chimney system for you:
The combustion air is transported from the outlet to the fireplace in counterflow to the flue gas and thus preheated. This prevents heat loss from the living rooms to the air duct and improves the efficiency of the connected fireplaces.
The combustion air is transported from the outlet to the fireplace in counterflow to the flue gas and thus preheated. This prevents heat loss from the living rooms to the air duct and improves the efficiency of the connected fireplaces.
The MULTI is specially designed for use in apartment buildings. It offers the option of connecting several gas fireplaces to one flue gas system. The finely graduated cross-sections of the MULTI allow precise adjustment to the nominal heat output of the fireplaces to be connected. Each individual boiler on the floor is fully operational and can be controlled individually. Fan-assisted, room-sealed gas fires with a closed combustion chamber are used for connection to the MULTI. In addition, the flue gas is routed exclusively through the thermal buoyancy of the chimney and via the connecting piece and the round fireclay inner pipe to the outside.
The MULTI is specially designed for use in apartment buildings. It offers the option of connecting several gas fireplaces to one flue gas system. The finely graduated cross-sections of the MULTI allow precise adjustment to the nominal heat output of the fireplaces to be connected. Each individual boiler on the floor is fully operational and can be controlled individually. Fan-assisted, room-sealed gas fires with a closed combustion chamber are used for connection to the MULTI. In addition, the flue gas is routed exclusively through the thermal buoyancy of the chimney and via the connecting piece and the round fireclay inner pipe to the outside.
The fireplace is easily connected to the supply air shaft and chimney via a concentric double pipe. This means that nothing stands in the way of on-site installation.
The fireplace is easily connected to the supply air shaft and chimney via a concentric double pipe. This means that nothing stands in the way of on-site installation.
Only the highest quality materials are used in the production of the MULTI system. The MULTI air extraction system was therefore designed for modern house construction and is ideal for apartment buildings.
Only the highest quality materials are used in the production of the MULTI system. The MULTI air extraction system was therefore designed for modern house construction and is ideal for apartment buildings.
The MULTI air flue system enables gas fireplaces to be operated independently of the room air. The closed design of the combination of supply air duct, fireplace and flue gas chimney ensures that flue gases cannot escape into adjacent rooms. Accidents caused by flue gas are therefore ruled out from the outset.
The MULTI air flue system enables gas fireplaces to be operated independently of the room air. The closed design of the combination of supply air duct, fireplace and flue gas chimney ensures that flue gases cannot escape into adjacent rooms. Accidents caused by flue gas are therefore ruled out from the outset. In addition, the chimney outlet is located above the supply air opening. It is separated from it by the outflow plate of the head section.
This prevents the flue gas and supply air from mixing. The supply air is transported to the fireplace in the annular gap formed by the concentric pipes and the flue gas is transported to the chimney in the inner pipe. The flue gases flow through the profiled ceramic inner pipe to the outside.
The MULTI air flue system enables gas fireplaces to be operated independently of the room air. The closed design of the combination of supply air duct, fireplace and flue gas chimney ensures that flue gases cannot escape into adjacent rooms. Accidents caused by flue gas are therefore ruled out from the outset.
