The classic UNI PLUS insulated chimney has a three-shell structure with rear ventilation, insulation board and fireclay inner pipe.
A closed air flue system with ceramic inner pipe for the room air-independent operation of gas floor heating systems.
Haven't found the right product yet? Use our online assistant to find the right product for your needs.
Find out more about the details and services for the ABSOLUT energy-saving chimney, such as the structure, detailed technical data or suitable services. You also have the option of downloading flyers or brochures about the product.
The ABSOLUT system is based on a foundation built on site onto which a prefabricated base is attached. This contains the inspection/cleaning door and all other components. After a ceiling duct, the flue pipe connection is attached to connect the fireplace. The chimney is topped off with an outlet cone and an air inlet head plate.
Basic data (dimensions, weight & co.) | |
Wall thickness per diameter (internal) |
7 - 12 mm |
Application | |
Flue gas temperature (dry) |
≤ 400 °C |
Material (Inner liner) |
Isostatic Ceramic |
Material (Insulation) |
Foamed concrete |
Material (Outer case) |
Lightweight concrete |
Thermal resistance by insulation thickness |
0,27 - 0,48 m²K/W |
General product features | |
Operating |
Negative pressure (N) |
Room sealed |
No, Yes |
Occupation |
Multi, Single |
Suitable for passive house |
Yes |
Heating technology |
Condensing boiler technology, Low temperature technology, Conventional heating technology |
At Schiedel, service is more than just a friendly voice on the phone. Service is an essential part of the Schiedel total package. In addition to product quality, safety, reliability and innovative strength as well as a good price-performance ratio, customer satisfaction is significantly influenced by our service. We offer the following services for the ABSOLUT energy-saving chimney:
Are you looking for tips or a sales advisor in your area? Simply enter your zip code and you will find the contact details of the sales advisor in your area.
In our FAQs you will find the most important answers to Schiedel products and their application.
Find the right contact person for our ceramics and stainless steel customer center here.
Are you a building contractor, architect or chimney sweep - a true professional? Then you've come to the right place. Enclosed you will find all relevant detailed information such as all relevant downloads (PDF files) for the product or our 3D CAD/BIM database.
Our online database gives you access to over 4,000 drawings for our stainless steel, ceramic and chimney systems. Register now and download.
